Reconfiguring a system 83
2 If the third cabinet is within 10 m (33 ft), add the cabinet to port 3.
Configure the cards required for expansion cabinet 3.
3 If the third cabinet is further than 10 m (33 ft), connect the two
short-haul cabinets to the dual-port daughterboards in ports 1 and 3.
4 Replace the lower 10 m (33 ft) expansion daughterboard in the main
cabinet with a 3 km (1.8 mi) expansion daughterboard.
5 Add the third (long-haul) cabinet to the single-port 3 km (1.8 mi)
expansion daughterboard in port 2.
6 Reassign in software all services provided on cards 21 to 30, to
cards 31 to 40.
—End—
Scenario 2: Adding a fourth expansion cabinet
The existing main cabinet is equipped with two 10 m (33 ft) dual-port
expansion daughterboards connecting to three expansion cabinets. A
remote expansion cabinet is to be added requiring a 3 km (1.8 mi) expansion
daughterboard. Although one of the existing daughterboards has a port
available, it can only be connected to a cabinet within 10 m (33 ft). With this
scenario, do the following:
Step Action
1 Select the dual-port expansion daughterboard that is being used for
only one cabinet (a spare port is available on the daughterboard).
2 Replace it with a 3 km (1.8 mi) dual-port expansion daughterboard.
3 Replace the receiver card in the existing companion expansion
cabinet with a 3 km (1.8 mi) receiver card.
4 With glass optic cable, connect the existing expansion cabinet to the
same port as previously assigned on the expansion daughterboard.
5 Add the cabinet to the remaining port as described in Procedure 3
"Adding expansion cabinets to an existing system" (page 81) .
—End—
