Trunk connections (UK) 363
Pair Pins Pair color Unit #
T7
R7
40
15 BK-S
S-BK
41
16 Y-BL
BL-Y
7
NT5K19 Analog TIE line trunk card terminations
Cross connect the NT5K19 analog TIE line trunk card as shown in Table 67
"NT5K19 2W paging mode terminations" (page 363) .
Note: The speech pairs on the NT5K19 card are polarity insensitive.
The E&M signalling pairs, however, are polarity sensitive. Make sure the
ground side of the trunk is connected to the A leg of the NT5K19 circuit.
Make sure the -50 V side of the trunk is connected to the B leg.
Table 67
NT5K19 2W paging mode terminations
Pair Pins Pair color Unit #
T0
R0
27
2
W-O
O-W
A
PG
29
4
W-BR
BR-W
0
T1
R1
31
6
R-BL
BL-R
A
PG
33
8
R-G
G-R
1
T2
R2
35
10 R-S
S-R
A
PG
37
12 BK-O
O-BK
2
T3
R3
39
14 BK-BR
BR-BK
A
PG
41
16 Y-BL
BL-Y
3
Table 68
NT5K19 2W Type 1 mode terminations
Pair Pins Pair color Unit #
T0
R0
27
2
W-O
O-W
E
M
28
3
W-G
G-W
0
