Circuit cards 211
Note 1: The NTDK16 provides three independent loops (loops
4, 5, and 6). When the time comes to program this card in
software, configure it as cards 4, 5, and 6 separately.
Note 2: Three LEDs provide card status.
Note 3: The NTDK16BA version of this card is not compatible
with the NTDK91AA and the NTDK91AB chassis.
—End—
NT8D02 Digital Line Card
The NTDK16 48-port Digital Line Card is functionally equivalent to three
NT8DO2 Digital Line Cards. However, the Chassis system also supports
the NT8D02 Digital Line Card.
You can install this card in:
• slots 1 through 10 in the main cabinet or slots 11 through 50 in the
expansion cabinets
• slots 1 through 3 in the chassis, slots 7 through 10 in the chassis
expander, or in the expansion chassis
Procedure 37
Installing the NT8D02 circuit card
Step Action
1 Insert the circuit card in its assigned slot.
—End—
Digital Trunk cards
Small Systems supports the following digital trunk cards:
• NTAK09 1.5 Mbit DTI/PRI
• NTAK10 2.0 Mbit DTI
• NTAK79 2.0 Mbit PRI
• NTBK22 MISP
• NTBK50 2.0 Mbit PRI
• NTRB21 1.5 Mbit DTI/PRI
• NT6D70 SILC (when used as a clock controller)
