Circuit cards 201
You can install this card in:
• slots 1 through 10 in the main cabinet or slots 11 through 50 in
the expansion cabinets
• slots 1 through 3 in the chassis, slots 7 through 10 in the chassis
expander, or in the expansion chassis
2 Configure and enable the card through LDs 13 and 34.
Note: After the card is enabled, the LED will flash three times to
indicate it is conducting a self-test. If the LED remains lit, then
the self-test has failed.
—End—
NT5K21 XMFC card
The NTDK20 SSC card provides the functionality of the Extended
Multi-Frequency Compelled Sender/Receiver (XMFC) card. However, the
XMFC card can coexist with the SSC card if you wish to access extra XMFC
capability.
The XMFC card provides four channels of R2 Standard signaling capability.
Procedure 33
Installing the XMFC card
Step Action
1 Insert the NT5K21 card in its assigned slot.
You can install this card in:
• slots 1 through 10 in the main cabinet or slots 11 through 50 in
the expansion cabinets
• slots 1 through 3 in the chassis, slots 7 through 10 in the chassis
expander, or in the expansion chassis
2 Configure and enable the card through LDs 13 and 34.
Note: After the card is enabled, the LED will flash three times to
indicate it is conducting a self-test. If the LED remains lit, then
the self-test has failed.
—End—
