336 Connecting the telephones
QUA6 J1 Cable
Function Pair Color Connects to
17T
17R
Y-O
O-Y Connect to the telephone
18T
18R
Y-G
G-Y Connect to the telephone line card
19T
19R
Y-BR
BR-Y Connect to the Central Office trunk
PFT 4
20T
20R
Y-S
S-Y Connect to the trunk line card
21T
21R
V-BL
BL-V Connect to the telephone
22T
22R
V-O
O-V Connect to the telephone line card
23T
23R
V-G
G-V Connect to the Central Office trunk
PFT 5
24T
24R
V-BR
BR-V Connect to the trunk line card
Table 49
Cable Pair Color Combinations
Color
W-Bl
Bl-W W-O
O-W W-G
G-W W-BR
BR-W W-S
S-W R-BL
BL-R R-O
O-R R-G
G-R
Unit 0 1 2 3 4 5 6 7
Color
R-BR
BR-R R-S
S-R BK-BL
BL-BK BK-O
O-BK BK-G
G-BK BK-BR
BR-BK BK-S
S-BK Y-B
B-Y
Unit 8 9 10 11 12 12 14 15
Cross-connecting terminal Digital Subscriber Loops
Refer to ISDN Basic Rate Interface Installation and Commissioning
(NN43001-318) for a complete description of terminal Digital Subscriber
Loops (DSL) cross-connecting and installation.
Activating telephones
Activating telephones is not difficult. Activate each telephone by performing
a procedure on the telephone. Automatic Set Configuration is the software
feature used to activate telephone sets.
Note: You cannot activate the data feature using the procedures in this
chapter. To program a telephone with the data feature, configure it in
LD 11 with Data Class of Service as described in Software Input Output
Reference - Maintenance (NN43001-711).
Nortel Communication Server 1000
Communication Server 1000M and Meridian 1 Small System Installation and Commissioning
NN43011-310 01.04 Standard
Release 5.0 13 May 2008
Copyright © 2008, Nortel Networks
.
