180
Installing IP expansion
Communication Server 1000M and Meridian 1 Small System Upgrade
(NN43011-459).
"Installing optional circuit cards" (page 193)
describes additional circuit
cards, which are optional to the Small System.
This chapter contains the following procedures:
•
Procedure 19 "Installing the software daughterboard and security
device" (page 160)
•
Procedure 27 "Installing the 100BaseT daughterboards on the SSC
card" (page 182)
•
Installing the NTDK20 SSC card on the Main Cabinet or Chassis
The following components must be installed on the SSC card before it is
inserted into the Main Cabinet or Chassis:
•
software daughterboard
•
security device
•
IP expansion daughterboard(s)
•
cables
Software daughterboard and security device
WARNING
The NTDK20 SSC card is equipped with components on both
sides of the circuit board. Be careful not to damage any of the
components when handling the card.
Procedure 26
Installing the software daughterboard and security device
Step
Action
1
Put on the antistatic wrist strap.
2
Place the SSC card on a clean, flat, electrostatic discharge
(ESD)-dissipated surface.
3
Install the software daughterboard on the connector as shown in
Figure 85 "Location of software daughterboard and security device
on the NTDK20 SSC card" (page 181)
