Trunk models 389
Trunk models
Note: All trunks are programmed as immediate start/supervision = Yes,
with the exception of trunks with an asterisk (*) next to them. Trunks
marked with an asterisk (*) are set for Wink start/supervision = Yes.
Table 94
Trunk model information
Mode Pack Model Signaling DIP or DTN BIMP and TIMP
COT XUT 1 GRD DIP 3COM/600
2 LOP DIP 3COM/600
3 GRD DTN 3COM/600
4 LOP DTN 3COM/600
5 GRD DIP 3COM/900
6 LOP DIP 3COM/900
7 GRD DTN 3COM/900
8 LOP DTN 3COM/900
TIE XUT 1 OAD DIP 3COM/600
2 LDR DIP 3COM/600
3 OAD DTN 3COM/600
4 LDR DTN 3COM/600
5 OAD DIP 3COM/900
6 LDR DIP 3COM/900
7 OAD DTN 3COM/900
8 LDR DIP 3COM/900
XEM 16 EAM DIP —/600
17 EM4 DIP —
18 EAM DTN —/ 600
19 EM4 DIP —
DID XUT 1 LDR
(Wink Start Supv = Yes)
DIP 3COM/600
2 LDR
(Wink Start Supv = Yes)
DTN 3COM/600
3 LDR
(Wink Start Supv = Yes)
DIP 3COM/900
4 LDR
(Wink Start Supv = Yes)
DTN 3COM/900
* These trunks are set for Wink start.
