Key expansion modules 443
base. Ensure that the ribbon cable(s) are not pinched between the
footstand and the mounting posts.
10 Insert the three (or four if you have two modules) self-tapping Phillips
head screws supplied with the key expansion module into the
mounting holes in the bottom of the footstand. Tighten the screws
firmly with a #1 Phillips screwdriver.
11 Tighten all screws, replace all cords and place the telephone in its
normal operating position. Place the label supplied with the key
expansion module(s) on the bottom cover of the telephone (or the
footstand) for tracking purposes.
12 Perform the self test and acceptance test procedures. (Refer to
Software Input/Output Administration (NN43001-611) for information
about these test procedures.)
—End—
Removing the key expansion module(s)
Use this procedure to remove one (single) or two (double) key expansion
modules to the M2616 or M2216 ACD CAP telephones.
Procedure 81
Removing a key expansion module
Step Action
1 Remove the telephone handset and place the telephone upside
down on top of a level, solid work surface covered with soft material
or paper to avoid damaging the keys or the telephone face.
2 Disconnect all cords from the telephone.
3 Remove the screws from the stand assembly (where it meets the
key expansion module) and unsnap the stand assembly from the key
expansion module and the telephone by pressing inward at the back
of the stand (where it meets the base) and pulling upward.
4 Remove the interface cable from the telephone by pressing down
on the locking tab. If you have an interface cable on the first key
expansion module (closest to the telephone), remove it now.
—End—
