Page 387
SDI ports
387
Modem port
The preconfigured modem port allows the remote maintenance modem
to be connected without further system programming. This port is
preconfigured as TTY 0 (port 0 on the SSC card) and is programmed for
Maintenance (MTC), Service Change (SCH), and BUG messages.
Enhanced Serial Data Interface (ESDI) port
Port 9 is preprogrammed as an ESDI port and supports Meridian Mail. It
functions as a Command and Status Link with the settings given in
Table 92
ESDI settings
Setting
Code
BPS
4800
CLOK
EXT
IADR
003
RADR
001
T1
10
T2
002
T3
040
N1
128
N2
08
K
7
RXMT
05
CRC
10
ORUR
005
ABOR
005
USER
CMS
ENL
NO
Telephone tones
The telephone tones in North America are as follows:
•
Dial tone: A continuous tone.
•
Special dial tone: Three beeps followed by continuous dial tone.
•
Overflow tone: Like a busy tone, except faster and higher.
•
Relocation tone: A short high-pitched beep that continues for 4
seconds, followed by silence.
Nortel Communication Server 1000
Communication Server 1000M and Meridian 1 Small System Installation and Commissioning
NN43011-310
01.04
Standard
Release 5.0
13 May 2008
Copyright © 2008, Nortel Networks
.
