Page 334
334
Connecting the telephones
Card
First TN......Last TN
Cable
Cabinet
36
36 00......36 15
J6
Expansion Cabinet 3
37
37 00......37 15
J7
Expansion Cabinet 3
38
38 00......38 15
J8
Expansion Cabinet 3
39
39 00......39 15
J9
Expansion Cabinet 3
40
40 00......40 15
J10
Expansion Cabinet 3
41
41 00.....41 15
J1
Expansion Cabinet 4
42
42 00......42 15
J2
Expansion Cabinet 4
43
43 00......43 15
J3
Expansion Cabinet 4
44
44 00......44 15
J4
Expansion Cabinet 4
45
45 00......45 15
J5
Expansion Cabinet 4
46
46 00......46 15
J6
Expansion Cabinet 4
47
47 00......47 15
J7
Expansion Cabinet 4
48
48 00......48 15
J8
Expansion Cabinet 4
49
49 00......49 15
J9
Expansion Cabinet 4
50
50 00......50 15
J10
Expansion Cabinet 4
Table 47
Terminal Number assignments: Chassis and chassis expander
Physical slot
Logical slot
First TN...Last TN
Cable
Chassis
1
1
01 00...01 15
Card 1
Main
2
2
02 00...02 15
Card 2
Main
3
3
03 00...03 15
Card 3
Main
4
4
5
6
04 00...04 15
05 00...05 15
06 00...06
07 06 08...06 15
Card 4/Card
6
Card 5/Card
6
Card 4/Card
6
Card 5/Card
6
(see note)
Main
Main
Main
Main
7
7
07 00...07 15
Card 7
Expander
8
8
08 00...08 15
Card 8
Expander
Note: Refer to the labels on the back of the chassis. See
Figure 106 "Cable connectors in a system
