Procedure 23 – Nortel Networks 1000M User Manual
Page 170
170
Installing fiber expansion
CAUTION
Service Interruption
Incorrectly connected fiber-optic cables may cause the following
problems:
•
a series of repetitive fault-indicating messages
•
a complete failure of the expansion cabinet
If fault-indicating messages appear, check the fiber-optic cable
connections.
Since messages are stored in a buffer, they may continue to
be displayed until the buffer is empty. After checking the cable
connections, wait a couple of minutes for the messages to stop.
Procedure 23
Installing the A0632902 10m plastic fiber-optic cable
Step
Action
1
Put on the antistatic wrist strap.
2
Place the SSC card on a clean, flat, ESD-dissipated surface.
3
Remove the protective plugs from the connectors on the Fiber
Expansion daughterboard.
4
Connect the fiber-optic cable to the Fiber Expansion daughterboard,
making sure that the "V"-shaped groove on the cable connector is
facing outward and that the connector is fully seated. See
"Plastic fiber cable connection on dual-port daughterboard" (page
171)
The mark (if equipped) on the sides of the cable connector should
not be visible when properly connected. Refer to
fiber cable connection on dual-port daughterboard" (page 171)
5
Route the fiber cable through the SSC cable router on the SSC card.
6
Insert the SSC card into slot 0 of the Main Cabinet or Chassis. Lock
card into faceplate latches.
7
Route the cables through the SSC Cable Routing Guide as shown in
Figure 79 "Fiber-optic cable connection" (page 172)
.
Note: Be sure to wrap the cable a minimum of one complete
loop around the Cable Routing Guide to allow for extra cable for
removing the SSC card later.
