Configuring IP Line data on survivable Small Systems
When the VGMC is installed in the Main Cabinet or Chassis, only one IP
address is required. When the card is installed in a survivable IP expansion
cabinet or chassis, two IP addresses are required. The first IP address is for
the Main Cabinet or Chassis SSC. The second IP address is for the SSC in
the survivable IP Expansion Cabinet or Chassis that has the VGMC.
Each IP Phone configured on the VGMC must have the IP address of the
survivable IP Expansion Cabinet or Chassis configured as the second IP
address. These IP addresses must be on the same subnet.
Refer to
Procedure 50 "Configuring the ELAN network interface IP address
for the Small System active ELNK Ethernet interfac" (page 265)
and
to configure the
Small System’s Main Cabinet or Chassis and any IP Expansion Cabinets
or Chassis.
Verifying VGMC operation in survival mode
To verify the operation of a VGMC in an IP Expansion Cabinet or Chassis in
survival mode, complete
Procedure 59 "Verifying the operation of a VGMC
in an IP Expansion Cabinet or Chassis in survival mode" (page 319)
.
Procedure 59
Verifying the operation of a VGMC in an IP Expansion Cabinet or Chassis
in survival mode
Step
Action
1
Go into LD 135 and use the SOTS command to force the IP
Expansion Cabinet or Chassis into survival mode.
The IP Expansion Cabinet or Chassis will reboot and come up in
survival mode.
When it is finished rebooting and in full operation, the VGMC on
the IP Expansion Cabinet or Chassis reboots and comes back up
communicating with the survivable IP expansion’s ELAN network
interface.
2
Check the IP Phones and TTY:
•
Local Mode is visible on the telephone display.
•
The Flexible Survivable Dial Tone is apparent.
•
Special text is also displayed on the remote TTYs connected to
the IP Expansion Cabinet or Chassis as shown below.
TTY 00 SCH MTC BUG CTY
14:10
SURVIVAL MODE
