Trunk connections 349
QUA6 J1 cable
Function Pair Color Connects to Comments
21T
21R
V-BL
BL-V
Connect to the telephone
22T
22R
V-O
O-V Connect to the telephone line
card Connect to TN assigned to the
telephone
23T
23R
V-G
G-V Connect to the Central Office
trunk
P
F
T
5
24T
24R
V-BR
BR-V
Connect to the trunk line card
Connect to TN assigned to the
trunk
Trunk connections
NT8D14 Universal Trunk card
The Universal Trunk card provides eight analog trunks which can function
in the modes shown in
Table 53 "NT8D14 Universal Trunk: modes and
option settings" (page 349) .
Table 53
NT8D14 Universal Trunk: modes and option settings
Modes Location Jumper strap
Central (CO) J1, J2 OFF
2-way TIE trunk (loop Dial Repeat) J1, J2 OFF
2 -way TIE trunk (Outgoing Incoming Dial) J1, J2 OFF
Recorded Announcement (RAN) J1, J2 OFF
Paging trunk J1, J2 OFF
Japan CO/DID operation J1, J2 OFF
DID operation
Loop length>2000 ohms J1, J2 ON
DID operation
Loop length <2000 ohms J1, J2 OFF
Note: OFF indicates no strap present.
J1 and J2 locations apply to all eight trunks.
Refer to Table 54 "NT8D14 Universal Trunk connections" (page 350) for the
connections to the NT8D14 Universal Trunk at the cross-connect terminal.
