200 Installing optional circuit cards
You can install this card in:
• slots 1 through 10 in the main cabinet or slots 11 through 50 in the
expansion cabinets
• slots 1 through 3 in the chassis, slots 7 through 10 in the chassis
expander, or in the expansion chassis
Procedure 31
Installing the E and M Trunk card
Step Action
1 Set the switches for the NT8D15 E&M trunk circuit card according to
Table 27 "NT8D15 E and M Trunk card option settings" (page 200) .
Table 27
NT8D15 E and M Trunk card option settings
Mode of operation J2 J9
4W — Type 1 ON connect pins 2 - 3
4W — Type 2 ON connect pins 2 - 3
2W — Type 1 ON connect pins 2 - 3
Paging trunk ON connect pins 2 - 3
2 Insert the card in its assigned slot.
—End—
NTAG26 XMFR card
The NTDK20 SSC card provides the functionality of the Extended
Multi-Frequency Receiver (XMFR) card. However, this card can exist with
the SSC card if you want to access additional XMFR capability.
The XMFR card receives MF digit information. Connections are made
between a PBX and a CO. Through the IPE MF Receiver, the Small System
supports features such as Automatic Number Identification (ANI), Meridian
911 (M911), and Feature Group D (FGD).
Procedure 32
Installing the XMFR card
Step Action
1 Insert the NTAG26 card in its assigned slot.
