372 Connecting an external alarm
Unit Pair Color Normal mode Failure mode
9T
9R
R-BR
BR-R Makes with 10T
and 10R Opens 10T and 10R
Makes with 11T and 11R
10T
10R
R-S
S-R Makes with 9T
and 9R Open
11T
11R
BK-BL
BL-BK Makes with 12T
and 12R Opens 12T and 12R
Makes with 9T and 9R
P
F
T
2
12T
12R
BK-O
O-BK Makes with 11T
and 11R Open
13T
13R
BK-G
G-BK Makes with 14T
and 14R Opens 14T and 14R
Makes with 15T and 15R
14T
14R
BK-BR
BR-BK Makes with 13T
and 13R Open
15T
15R
BK-S
S-BK Makes with 16T
and 16R Opens 16T and 16R
Makes with 13T and 13R
P
F
T
3
16T
16R
Y-BL
BL-Y Makes with 15T
and 15R Open
17T
17R
Y-O
O-Y Makes with 18T
and 18R Opens 18T and 18R
Makes with 19T and 19R
18T
18R
Y-G
G-Y Makes with 17T
and 17R Open
19T
19R
Y-BR
BR-Y Makes with 20T
and 20R Opens 20T and 20R
Makes with 17T and 17R
P
F
T
4
20T
20R
Y-S
S-Y Makes with 19T
and 19R Open
21T
21R
V-BL
BL-V Makes with 22T
and 22R Opens 22T and 22R
Makes with 23T and 23R
22T
22R
V-O
O-V Makes with 21T
and 21R Open
23T
23R
V-G
G-V Makes with 24T
and 24R Opens 24T and 24R
Makes with 21T and 21R
P
F
T
5
24T
24R
V-BR
BR-V Makes with 23T
and 23R Open
