354 Connecting the trunks
Lead designations Pins Pair color Unit number
T1
R1
E1
E2
M1
M2
31
6
32
7
33
8
R-BL
BL-R
R-O
O-R
R-G
G-R
Unit
1
T2
R2
E1
E2
M1
M2
35
10
36
11
37
12
R-S
S-R
BK-BL
BL-BK
BK-O
O-BK
Unit
2
T3
R3
E1
E2
M1
M2
39
14
40
15
41
16
BK-BR
BR-BK
BK-S
S-BK
Y-BL
BL-Y
Unit
3
E and M TIE trunk card (4-wire)
Table 58
E and M TIE trunk card (4-wire)
Cables
J1 through J10 from
cabinet/Card 1 through
Typical lead designations
Unit # Pins
