Cables and wires

Cable and wire

Purpose and description

NTAK19 cable

SDI cable used with the NTAK02 circuit card
(see Note 1).

NTAK1118/1118 9- to 25-pin RS232 converter
cable

Connects SDI ports and terminals (see Note 1).

A0378652 F-F DCE to DTE converter, or
A0381016 F-M DCE to DTE converter

Connects SDI ports to equipment, such as TTYs
and modems.

NTBK04 1.5 Mbit DTI/PRI carrier cable
(A0394216)

Connects the NTAK09 1.5 Mbit DTI/PRI card to
the Channel Service Unit (CSU). The NTBK04
carries Tx and Rx pairs to a standard 5-pin
connector.

NTBK05AA/DA 2.0 Mbit DTI/PRI carrier cable
A0394217

Carries Tx and Rx pairs to a standard 120-Ohm
D-connector (see Note 1).

NT8D7205

DTI/PRI carrier cable

NTBK05CA coaxial cable
NTBK05DA twisted pair cable
NTAK10 2.0 Mbit DTI cable
NTAK79 2.0 Mbit PRI cable
NTAK50 2.0 Mbit PRI cable

These cables provide DTI/PRI connections. The
cables carry Tx and Rx pairs to a standard 5-pin
connector (see Note 2).

25-pair inside wiring cables equipped with
amphenol-type connectors

Extend the Intelligent Peripheral Equipment
connections from the system chassis to the
cross-connect terminal, and connect PFTUs.

#6 AWG (#40 Metric Wire Gauge) insulated
ground wire

Connects a system cabinet to a building ground
source.

#6 AWG (10 mm

) insulated ground wire (UK)

Connects a system cabinet to a building ground
source.

#6 AWG (20 mm

) insulated ground wire

(Europe)

Connects a cabinet to a building ground source.

#8 AWG (10 mm

) insulated ground wire

(Germany)

Connects a cabinet to a building ground source.

Cross-connect wire

Makes cross connections at the cross-connect
terminal.

Note 1: This cable is available in different versions, depending on local EMC specifications.

Note 2: These cables are not supported under EMC specifications VL43.140P.

lists the AC power cord kits for

various countries. These cords connect a system cabinet to a commercial
AC power source.
