Installing IP expansion
Contents
This section contains information on the following topics:
"Installing the NTDK20 SSC card on the Main Cabinet or Chassis" (page 180)
"Software daughterboard and security device" (page 180)
"IP expansion daughterboards and cables" (page 182)
"Installing the NTDK20 SSC card on IP expansion cabinets and chassis" (page
190)
"Software daughterboard and security device" (page 190)
"IP expansion daughterboards and cables" (page 190)
Introduction
This chapter describes how and where to install the Small System Controller
(SSC) cards, software and expansion daughterboards, and cables required
for IP expansion. The chapter includes information relevant to the Main and
IP Expansion Cabinets or Chassis.
Note: In a CS 1000M Cabinet or Chassis system, the NTDK20 SSC
card is also referred to as the Call Server.
For IP expansion, you must install an SSC card, equipped with a software
daughterboard and IP expansion daughterboard(s), in slot 0 of the Main
Cabinet or Chassis. You must also install an SSC card, equipped with an
IP expansion daughterboard and a software daughterboard, in slot 0 of
the Expansion Cabinet or Chassis.
Note: The main cabinet and all chassis require SSC card vintage
NTDK20HA or newer, or upgraded NTDK20EA-GA (upgraded using the
NTTK19 SSC Upgrade Kit). An expansion cabinet requires SSC card
vintage NTDK20HA or newer, or upgraded NTDK20CA-GA (upgraded
using the NTTK19 SSC Upgrade Kit). For information on upgrading an
SSC card, refer to the chapter on upgrading system controller cards in
