164 Installing fiber expansion
This chapter contains the following procedures:
• Procedure 19 "Installing the software daughterboard and security
device" (page 160)
• Procedure 21 "Installing the single-port Fiber Expansion daughterboards
on the SSC card" (page 166)
• Procedure 22 "Installing the dual-port Fiber Expansion daughterboards
on the SSC card" (page 167)
• Procedure 23 "Installing the A0632902 10m plastic fiber-optic cable"
(page 170)
• Procedure 24 "Installing glass fiber-optic cable" (page 172)
• Procedure 25 "Installing the Fiber Receiver card" (page 174)
Installing the NTDK20 SSC card on the Main Cabinet or Chassis
The following components must be installed on the SSC card before it is
inserted into the Main Cabinet or Chassis:
• software daughterboard
• security device
• fiber expansion daughterboard(s)
• cables
Software daughterboard and security device
WARNING
The NTDK20 SSC card is equipped with components on both
sides of the circuit board. Be careful not to damage any of the
components when handling the card.
Procedure 20
Installing the software daughterboard and security device
Step Action
1 Put on the antistatic wrist strap.
2 Place the SSC card on a clean, flat, electrostatic discharge
(ESD)-dissipated surface.
3 Install the software daughterboard on the connector as shown in
Figure 74 "Location of software daughterboard and security device
on the NTDK20 SSC card" (page 165)
.
