PFTU installation 231
J1 Cable from QUA6 (see Figure 113 "Power fail transfer" (page 234) )
Function
Pair
Number
Pair
Color Connects to Cross-connect to
2T W-O PFTS W-O 1-dot connection on
AUX cable from the cabinet
or chassis. Transfer begins
by applying ground to this
lead.
2R O-W BRTN BL-W 1-dot connection on
AUX cable from the cabinet
or chassis.
3T W-G (TC) Console transfer switch.
See console connections.
Transfer begins by applying
ground to this lead.
3R G-W Not used.
4T W-BR Not used.
4R BR-W Not used.
PFTU power
25T
25R S-V
V-S -48 V
-48 V O-W 1-dot connection on
AUX cable. Maximum 250
mA draw on O-W lead.
