Configuring Axes
Chapter 3
3-12
Once you have selected the servo hardware, you are prompted to select the
type of servo loop you will be using.
b.
Select a Servo Loop Type. This is the type of servo loop(s) you
expect the 9/SERIES control to close. Select between:
Servo Loop Type:
Results in:
None
This is the default setting that the control uses when no loop type has
been selected. The control stays in E-stop if an axis type has been
defined, and no loop type has been defined.
Position or Spindle
The control closes the position loop only. However, this selection is
also used for spindles (excluding digital spindles) and depth probes.
Position/Velocity
The control will close both the position loop and the velocity loop.
Separate devices or the same feedback device can be used to close
both the position and velocity loops.
Digital
The control will close both the position and the velocity loop.
Additionally, motor information necessary for proper commutation is
also provided for digital drive systems. This must be selected for all
digital drive systems (including 1394 systems as spindles)
Once you have selected the servo hardware type and servo loop type,
additional AMP parameters become available to you for configuration in
the Servo Parameters Group.
The control can be configured for display and input in several different
types of units. To select units of the open AMP file:
1.
Press [F3] to pull down the Options menu.
The workstation displays this screen:
Proj:
AMPTEST
Appl:
AMP
Util:
Edit
F2-Project F3-Application F4-Utility
F5-Configuration
F1-File
F2-Axis
F3-Options
F4-Quick Edit!
F5-Process
Type : Lathe
AXIS: X
P1:
Axis Parameters
Home Parameters
Zone/Overtravel Parameters
Servo Parameters
Jog Parameters
Feedrate Parameters
Acc/Dec Parameters
CSS Parameters
Spindle 1 Parameters
Spindle 2 Parameters
Spindle 3 Parameters
Axis Program Format
Letter Format
Plane Select
Page 1 of 3
File :
TEST
File :
TEST
Feet
(a)
Ö Inches
(b)
Meters
(c)
Centimeters
(d)
Millimeters
(e)
Ö Degrees
(f)
Revolutions
(g)
Seconds
(h)
Ö Minutes
(i)
Control Type
(j)
The checked (Ö) units are current settings.
3.7
Selecting Units
