Paramacro Parameters
Chapter 21
21-2
Proj:
AMPTEST
Appl:
AMP
Util:
Edit
F2-Project F3-Application F4-Utility
F5-Configuration
F1-File
F2-Axis
F3-Options
F4-Quick Edit!
Control Type : Mill
Axis :
X - linear
File :
TEST
- Paramacro Parameters -
Page 7 of 7
G-CODE FOR MACRO CALL 15
:
245.0
TYPE OF MACRO CALL 15
:
NOT USED
PROGRAM # FOR MACRO CALL 15
:
15
Proj:
AMPTEST
Appl:
AMP
Util:
Edit
F2-Project F3-Application F4-Utility
F5-Configuration
F1-File
F2-Axis
F3-Options
F4-Quick Edit!
Control Type : Mill
Axis :
X - linear
File :
TEST
- Paramacro Parameters -
Page 6 of 7
PROGRAM # FOR MACRO CALL 10
:
10
G-CODE FOR MACRO CALL 11
:
241.0
TYPE OF MACRO CALL 11
:
NOT USED
PROGRAM # FOR MACRO CALL 11
:
11
G-CODE FOR MACRO CALL 12
:
242.0
TYPE OF MACRO CALL 12
:
NOT USED
PROGRAM # FOR MACRO CALL 12
:
12
G-CODE FOR MACRO CALL 13
:
243.0
TYPE OF MACRO CALL 13
:
NOT USED
PROGRAM # FOR MACRO CALL 13
:
13
G-CODE FOR MACRO CALL 14
:
244.0
TYPE OF MACRO CALL 14
:
NOT USED
PROGRAM # FOR MACRO CALL 14
:
14
Proj:
AMPTEST
Appl:
AMP
Util:
Edit
F2-Project F3-Application F4-Utility
F5-Configuration
F1-File
F2-Axis
F3-Options
F4-Quick Edit!
Control Type : Mill
Axis :
X - linear
File :
TEST
- Paramacro Parameters -
Page 5 of 7
TYPE OF MACRO CALL 6
:
NOT USED
PROGRAM # FOR MACRO CALL 6
:
6
G-CODE FOR MACRO CALL 7
:
237.0
TYPE OF MACRO CALL 7
:
NOT USED
PROGRAM # FOR MACRO CALL 7
:
7
G-CODE FOR MACRO CALL 8
:
238.0
TYPE OF MACRO CALL 8
:
NOT USED
PROGRAM # FOR MACRO CALL 8
:
8
G-CODE FOR MACRO CALL 9
:
239.0
TYPE OF MACRO CALL 9
:
NOT USED
PROGRAM # FOR MACRO CALL 9
:
9
G-CODE FOR MACRO CALL 10
:
240.0
TYPE OF MACRO CALL 10
:
NOT USED
Proj:
AMPTEST
Appl:
AMP
Util:
Edit
F2-Project F3-Application F4-Utility
F5-Configuration
F1-File
F2-Axis
F3-Options
F4-Quick Edit!
Control Type : Mill
Axis :
X - linear
File :
TEST
- Paramacro Parameters -
Page 4 of 7
G-CODE FOR MACRO CALL 2
:
232.0
TYPE OF MACRO CALL 2
:
NOT USED
PROGRAM # FOR MACRO CALL 2
:
2
G-CODE FOR MACRO CALL 3
:
233.0
TYPE OF MACRO CALL 3
:
NOT USED
PROGRAM # FOR MACRO CALL 3
:
3
G-CODE FOR MACRO CALL 4
:
234.0
TYPE OF MACRO CALL 4
:
NOT USED
PROGRAM # FOR MACRO CALL 4
:
4
G-CODE FOR MACRO CALL 5
:
235.0
TYPE OF MACRO CALL 5
:
NOT USED
PROGRAM # FOR MACRO CALL 5
:
5
G-CODE FOR MACRO CALL 6
:
236.0
Proj:
AMPTEST
Appl:
AMP
Util:
Edit
F2-Project F3-Application F4-Utility
F5-Configuration
F1-File
F2-Axis
F3-Options
F4-Quick Edit!
F5-Process
Type : Mill
AXIS: X
P1:
File :
TEST
- Paramacro Parameters -
Page 3 of 7
M-CODE FOR CALL TO #9002 OR -1
:
992
M-CODE FOR CALL TO #9003 OR -1
:
993
M-CODE FOR CALL TO #9004 OR -1
:
994
M-CODE FOR CALL TO #9005 OR -1
:
995
M-CODE FOR CALL TO #9006 OR -1
:
996
M-CODE FOR CALL TO #9007 OR -1
:
997
M-CODE FOR CALL TO #9008 OR -1
:
998
M-CODE FOR CALL TO #9009 OR -1
:
999
FUNC OF AMP-DEFINED G/M IN MD1
:
works as a macro call
FUNC OF CALLED AMP MACRO
:
works as the system-defined code
G-CODE FOR MACRO CALL 1
:
231.0
TYPE OF MACRO CALL 1
:
NOT USED
PROGRAM # FOR MACRO CALL 1
:
1
