Configuring Axes
Chapter 3
3-10
3. Select the axis from which to copy.
The workstation displays this screen:
Proj: TEST Appl: AMP Util: Edit
F2-Project F3-Application F4-Utility F5-Configuration F1-File F2-Axis F3-Options F4-Quick Edit!
Control Type : Mill Axis : X - linear File : TEST
Axis Parameters
Home Parameters
Zone/Overtravel Parameters
Digital Servo Parameters
Analog Servo Parameters
Spindle 1 Parameters
Jog Parameters
Feedrate Parameters
Acc/Dec Parameters
CSS Parameters
Power-up G Codes
Cutter Comp/Tool Tip Radius
Paramacro Parameters
Axis Program Format
Page 1 of 2
Copy from Axis 1 to Axis...:
----------------------------------------------------------------
Axis [1]
: X linear - 4 Axis Digital (8520) - Position (1)
Axis [2] : Y linear - 4 Axis Digital (1394) - Position (2)
Axis [3] : Z linear - NONE - NONE (3)
Axis [4] : U unfitted - NONE - NONE (4)
Axis [5] : V unfitted - NONE - NONE (5)
Axis [6] : W unfitted - NONE - NONE (6)
Axis [7] : C unfitted - NONE - NONE (7)
Axis [8] : A unfitted - NONE - NONE (8)
Axis [9] : B unfitted - NONE - NONE (9)
Axis [10] : S unfitted - NONE - NONE (a)
Axis [11] : S unfitted - NONE - NONE (b)
Axis [12] : S unfitted - NONE - NONE (c)
Axis [13] : S unfitted - NONE - NONE (d)
Axis [14] : S unfitted - NONE - NONE (e)
Axis [15] : S unfitted - NONE - NONE (f)
4. Select the axis that will receive the copy of the axis parameters.
The workstation copies the parameter values from the selected source
axis to the selected destination axis.
Important: The two axes must be of the same type. For example, a linear
axis can only be copied to another linear axis.
