Page 481

Tool Offset Parameters
Chapter 22
22-9
Notes
This is a global parameter; the value set here applies to all axes. This
parameter does not affect the operation of the cutter compensation or the
TTRC features in any way.
Important: It is incompatible to select a geometry offset mode of “immed
shift, immed move” when the wear offset mode is configured as “immed
shift, delay move” or a geometry offset mode of “immed shift, delay
move” and a wear offset mode of “immed, shift immed move”. An error
message (INCOMPATIBLE TOOL ACTIVATION MODES) is displayed
and the control is held in E-STOP when the wear and geometry activation
mode is incompatible.
For Dual Processing controls, this is a per process parameter. The value set
in the parameters applies to all of the axes assigned to that process.
This parameter is not available for grinder applications.
Function
Use this parameter to determine what tool offsets are canceled when a
control reset is performed. These offsets can still be activated, canceled, or
replaced by the programmer at any time. You can configure your system
to perform a control reset whenever an E-STOP reset is performed using
the parameter Control Reset on E-STOP Reset (page 37-4).
Axis
Parameter Number
Single Process
Process 1
Process 2
All
[204]
[20204]
[21204]
Do Not Cancel -- When “do not cancel” is selected for this parameter, the
control does not cancel the offset values when a control reset is executed.
Cancel Wear Only -- When “cancel wear only” is selected for this
parameter, the control cancels only the wear offset when a control reset is
executed. Any geometry offset that is active is not canceled.
Cancel Geom & Wear -- When “cancel geom & wear” is selected for this
parameter, the control cancels both geometry and wear tool offset data
when a control reset is executed.
Cancel Geometry Offset -- when you select “cancel geometry offset” for
this parameter, the control cancels both length offset and radius/orientation
offset when a control reset is executed.
22.7
Tool Offset Cancel
