Jog Parameters
Chapter 8
8-7
There are five Jog Speed parameters used to set the speed at which
continuous jogs take place:
Parameter:
Page:
Lowest Jog Speed
8-8
Second Jog Speed
8-9
Third Jog Speed
8-10
Fourth Jog Speed
8-11
Highest Jog Speed
8-12
Important: Incremental jogs jog at the value assigned to the Third Jog
Speed parameter. This value may be overridden by the PAL program.
The value specified for each of the five jog speed parameters is equal to
the speed at which a continuous jog move takes place (unless that jog is
selected as a “Traverse” jog). These five parameters correspond to the five
selections under
continuous jog takes place. If the continuous jog is selected as a traverse
jog, then the
traverse jog speed is used.
The jog speed parameters may range between the following values;
however, keep in mind that none of the values for these parameters may
overlap (the feedrates must increase or stay the same as the higher switch
positions are set). This does not apply to the traverse jog speed. This is
the acceptable range for jog speeds:
0.00600 to 243840.00000 mmpm.
or
0.00024 to 9600.00000 ipm.
The default setting for
panel is LOW X1.
8.3
Jog Speeds
