Letter Format Parameters
Chapter 17
17-2
When you select the “Letter Format” group and the control type “Lathe,”
the workstation displays these screens:
Proj:
AMPTEST
Appl:
AMP
Util:
Edit
F2-Project F3-Application F4-Utility
F5-Configuration
F1-File
F2-Axis
F3-Options
F4-Quick Edit!
F5-Process
Type : Lathe
AXIS: X
- linear
P1:
File :
TEST
- Letter Format -
Page 2 of 2
Proj:
AMPTEST
Appl:
AMP
Util:
Edit
F2-Project F3-Application F4-Utility
F5-Configuration
- Letter Format -
Page 1 of 2
S: Orient Angle Word Format
:
3.0 degrees
S: Spindle RPM Word Format
:
4.0 rpm
T: Tool Number Integer Format
:
4.0
,C/,R Word Format
:
4.4 inch and 5.3 metric
D: Integer Format
:
4.0
D: Word Format
:
4.4 ipm
5.3 mmpm
E: # THRDS/INCH Word Format
:
3.4 threads per inch
F: IPM/MMPM Word Format
:
4.4 ipm
5.3 mmpm
F: IPR/MMPR Word Format
:
2.5 ipr
3.4 mmpr
Lead: Word Format
:
2.5 ipr
3.4 mmpr
P dwell type : integer/decimal
:
Decimal format
P: Integer Format
:
4.0
Q: Integer Format
:
5.0
Q: Word Format
:
4.4 inch and 5.3 metric
Q: Thread Marker Angle Shift
:
3.0 degrees
R: Word Format
:
4.4 inch and 5.3 metric
S: CSS Word Format
:
3.2 ft/min
2.3 meters/min
F1-File
F2-Axis
F3-Options
F4-Quick Edit!
F5-Process
Type : Lathe
AXIS: X
- linear
P1:
File :
TEST
These parameters are described on these pages:
Parameter:
Page:
D Integer and Word Formats
17-3
E Word Format
17-5
F Word Formats
17-6
H Integer and Word Formats
17-9
Lead Word Format
17-11
P Word Format
17-12
Q Integer and Word Formats
17-14
R Word Formats
17-17
S Word Formats
17-19
T Word Format
17-22
Chamfering/Corner-R Word Letter Formats
17-23
