Chapter
9
9-1
Feedrate Parameters
This section describes the parameters that affect programmed feedrates,
with the exception of jogging feedrates (which are discussed in chapter 9).
We describe these programmed feedrate parameters:
Parameter: Page:
Standard Motion Feedrate parameters 9-2
Feedrate Override parameters 9-4
Single Digit Feedrate (F1 through F9) parameters 9-9
Skip, Gauge, and Probing cycles, feedrate parameters 9-10
When you select the “Feedrate Parameters” group from the main menu
screen, these parameter screens become available:
Proj: AMPTEST Appl: AMP Util: Edit
F2-Project F3-Application F4-Utility F5-Configuration F1-File F2-Axis F3-Options F4-Quick Edit! F5-Process
Type : Mill AXIS :X - linear P1: File : TEST
- Feedrate Parameters -
Page 2 of 2
Proj: AMPTEST Appl: AMP Util: Edit
F2-Project F3-Application F4-Utility F5-Configuration F1-File F2-Axis F3-Options F4-Quick Edit! F5-Process
- Feedrate Parameters -
Page 1 of 2
Feedrate for F7 : 177.79980 mmpm
Feedrate for F8 : 203.19960 mmpm
Feedrate for F9 : 228.60000 mmpm
G31/G31.1/G37/G371Skip Feed : 0.00000 mmpm
G31.2/G37.2 Skip Feedrate : 0.00000 mmpm
G31.3/G37.3 Skip Feedrate : 0.00000 mmpm
G31.4/G37.4 Skip Feedrate : 0.00000 mmpm
Circ. error tolerance limit : 0.05000 mm
Rapid feedrate for positioning (1) : 10160.00004 mmpm
Maximum cutting feedrate (1) : 2539.99980 mmpm
Use AMP Skip Feedrate : no
Rapid Override in Dry Run : True
“F1” Rapid override percent : 0 %
External decel speed (cutting) : 25.39980 mmpm
External decel speed (posit.)(1) : 253.99980 mmpm
Feedrate for F1 : 25.39980 mmpm
Feedrate for F2 : 50.79960 mmpm
Feedrate for F3 : 76.20000 mmpm
Feedrate for F4 : 101.59980 mmpm
Feedrate for F5 : 126.99960 mmpm
Feedrate for F6 : 152.40000 mmpm
Type : Mill AXIS :X - linear P1: File : TEST
9.0
Chapter Overview
