Patch AMP
Chapter 41
41-18
Parameter Patch AMP Value Default Value Parameter Name
1330
2330
3330
Negative Software Overtravel 0.00000 mm --2540000.00000 to 2540000.00000
mm
1340
2340
3340
Reversal Error Compensation 0.00000 mm --9.99900 to 9.99900 mm
1350
2350
3350
Home Speed from Limit Switch 4.2333 mm/sec 0.0001 to 169.3333 mm/sec
1510
2510
3510
Servo Position Loop Type Closed Loop 0 -- Open Loop for Analog Only
1 -- Closed Loop
2 -- ZFE Closed Loop
3 -- Servo Off
4 -- Servo Detached
5 -- Depth Probe
1560
2560
3560
Velocity Feedback Type INC Encoder U/V/W on
Dig. Mod.
0 -- No Feedback
1 -- ABS Encoder
2 -- INC Encoder U/V/W channel
3 -- INC Encoder -- A/B/Z (Z
4 -- INC Encoder -- A/B/Z (Z>A)
1565
2565
3565
Velocity Feedback Counts/Cycle 2000 4 to 4,194,304
1570
2570
3570
Position Feedback Type INC Encoder
A/B/Z (Z
0 -- No Feedback
1 -- ABS Encoder on Dig. Mod.
2 -- INC encoder U/V/W channel on
Dig. Mod.
3 -- INC Encoder -- A/B/Z (Z
4 -- INC Encoder -- A/B/Z (Z>A)
1575
2575
3575
Position Feedback Counts/Cycle 2000 4 to 4,194,304
1580
2580
3580
Maximum Motor Speed 2200 rpm 0 to 99,999 rpm
1590
2590
3590
Lead screw thread pitch 2.540 mm 0.000 to 254.000 mm
1595
2595
3595
Sign of Position Feedback Plus 1 -- Plus
--1 -- Minus
1600
2600
3600
Sign of Velocity Feedback Plus 1 -- Plus
--1 -- Minus
1660
2660
3660
Peak Current as a % of RMS 200% 200 -- 200%
300 -- 300%
