11 end face milling incremental axis – Rockwell Automation 8520-ARM2 9/Series CNC AMP Reference Manual Documentation Set User Manual
Page 574

Cylindrical/Virtual C Parameters
Chapter 30
30-10
Function
Important: The End Face Milling Incremental Axis parameter is used
only for lathe type A.
This parameter specifies the name of the machine axis that will be end face
milling incremental axis during virtual C end face milling. This
incremental axis will be perpendicular to the diameter and feed axes during
virtual C end face milling.
Important: The machine axis named as the end face milling incremental
axis must not be an axis in the current machine configuration.
Parameter
Parameter Number
Single Process
Process 1
Process 2
End Face Milling Incremental Axis
[239]
[20239]
[21239]
Range
Selection
Result
Selection
Result
(a)
A
(f)
W
(b)
B
(g)
X
(c)
C
(h)
Y
(d)
U
(i)
Z
(e)
V
(j)
none
Notes
This parameter is used for lathe controls only.
In the dual--processing lathe, this is a per process parameter. The value set
in the parameters applies to all of the axes assigned to that process.
This feature is not available on the 9/230 control.
30.11
End Face Milling
Incremental Axis
