Power-up G-code Parameters
Chapter 19
19-2
Access these parameters by selecting the “Power-up G Codes” parameter
group displayed on the main AMP menu screen. When you select the
“Power-up G Codes” parameter group, the workstation displays
this screen:
Proj:
AMPTEST
Appl:
AMP
Util:
Edit
F2-Project F3-Application F4-Utility
F5-Configuration
F1-File
F2-Axis
F3-Options
F4-Quick Edit!
Control Type:
Lathe
Axis :
X - linear
File :
TEST
- Power-up G Codes -
These parameters appear only if the
selected application type is Lathe.
PTO G code for modal group 5
: IPM/MMPM
PTO G code for modal group 6
: Inch mode
PTO G code for modal group 1
: G01
PTO Plane Select G-code
: G18
PTO G code for modal group 3
: G90
PTO G code for modal group 10
: Init Level Return
PTO G code for modal group 13
: G64 (Cutting Mode)
PTO G code for modal group 18
: G07 (Radius)
PTO G code for modal group 20
: G39 (Cutter Comp Linear)
PTO G code for modal group 22
: G36 (Short Block Feed Clamped)
PTO Work Coordinate
: NONE
PTO G code for modal group 4
: G23
PTO ACC/DEC Mode
: G47 (Linear ACC/DEC)
Your screens may differ slightly, depending on your application.
These parameters are covered on these pages:
Parameter:
Page:
PTO G--code for modal group 5
19-3
PTO G--code for modal group 6
19-4
PTO G--code for modal group 1
19-5
PTO plane select G-code
19-6
PTO G--code for modal group 3
19-7
PTO G--code for modal group 8
19-8
PTO G--code for modal group 18
19-9
PTO work coordinate
19-10
PTO G--code for modal group 4
19-11
CSS (On/Off)
19-12
PTO G--code for modal group 10
19-13
PTO G--code for modal group 13
19-14
PTO G--code for modal group 15
19-15
PTO G--code for modal group 20
19-16
PTO G--code for modal group 22
19-17
PTO ACC/DEC mode
19-18
For details on specific G-codes and their meanings, refer to one of your
programming and operation manuals.
19.1
PTO G- code
