Home Parameters

Chapter 5

5-13

Axis

Parameter

Number

Axis

Parameter

Number

(1)

[1310]

(7)

[7310]

(2)

[2310]

(8)

[8310]

(3)

[3310]

(9)

[9310]

(4)

[4310]

(10)

[10310]

(5)

[5310]

(11)

[11310]

(6)

[6310]

(12)

[12310]

Range

--2450000.00000 to 2450000.00000 mm

or

--100000.00000 to 100000.00000 in.

Notes

For example, the home position for the lathe axis that moves toward the

chuck (typically called the Z axis) is usually at the opposite end of travel

from the chuck. A high positive value entered here as the home position

coordinate would result in the chuck face having a coordinate value at or

near zero.

This parameter is not used for systems that use distance coded marker

linear feedback devices.

This parameter must be set independently for each axis.
