Chapter
29
29-1
Solid- tapping Parameters
Solid--tapping parameters let you specify AMP ramps and maximum
tapping speeds for each gear of each spindle. The two types of
solid--tapping parameters are acceleration time and maximum tapping
speed.
When you select the “Solid--tapping Parameters” group from the main
menu in AMP, the workstation displays these screens:
Proj:
AMPTEST
Appl:
AMP
Util:
Edit
F2-Project F3-Application F4-Utility
F5-Configuration
F1-File
F2-Axis
F3-Options
F4-Quick Edit!
F5-Process
Type : Lathe
AXIS: X
- linear
P1:
File :
TEST
- Solid Tapping Parameters -
Page 1 of 4
Acc time for Spindle 1, Gear 1
:
0.50000 seconds
Acc time for Spindle 1, Gear 2
:
0.50000 seconds
Acc time for Spindle 1, Gear 3
:
0.50000 seconds
Acc time for Spindle 1, Gear 4
:
0.50000 seconds
Acc time for Spindle 1, Gear 5
:
0.50000 seconds
Acc time for Spindle 1, Gear 6
:
0.50000 seconds
Acc time for Spindle 1, Gear 7
:
0.50000 seconds
Acc time for Spindle 1, Gear 8
:
0.50000 seconds
Acc time for Spindle 2, Gear 1
:
0.50000 seconds
Acc time for Spindle 2, Gear 2
:
0.50000 seconds
Acc time for Spindle 2, Gear 3
:
0.50000 seconds
Acc time for Spindle 2, Gear 4
:
0.50000 seconds
Acc time for Spindle 2, Gear 5
:
0.50000 seconds
Proj:
AMPTEST
Appl:
AMP
Util:
Edit
F2-Project F3-Application F4-Utility
F5-Configuration
F1-File
F2-Axis
F3-Options
F4-Quick Edit!
F5-Process
Type : Lathe
AXIS: X
- linear
P1:
File :
TEST
- Solid Tapping Parameters -
Acc time for Spindle 2, Gear 6
:
0.50000 seconds
Acc time for Spindle 2, Gear 7
:
0.50000 seconds
Acc time for Spindle 2, Gear 8
:
0.50000 seconds
Acc time for Spindle 3, Gear 1
:
0.50000 seconds
Acc time for Spindle 3, Gear 2
:
0.50000 seconds
Acc time for Spindle 3, Gear 3
:
0.50000 seconds
Acc time for Spindle 3, Gear 4
:
0.50000 seconds
Acc time for Spindle 3, Gear 5
:
0.50000 seconds
Acc time for Spindle 3, Gear 6
:
0.50000 seconds
Acc time for Spindle 3, Gear 7
:
0.50000 seconds
Acc time for Spindle 3, Gear 8
:
0.50000 seconds
Max tap speed for Spn 1, Gear 1
:
500.0 rpm
Max tap speed for Spn 1, Gear 2
:
500.0 rpm
Page 2 of 4
Proj:
AMPTEST
Appl:
AMP
Util:
Edit
F2-Project F3-Application F4-Utility
F5-Configuration
F1-File
F2-Axis
F3-Options
F4-Quick Edit!
F5-Process
Type : Lathe
AXIS: X
- linear
P1:
File :
TEST
- Solid Tapping Parameters -
Page 3 of 4
Max tap speed for Spn 1, Gear 3
:
500.0 rpm
Max tap speed for Spn 1, Gear 4
:
500.0 rpm
Max tap speed for Spn 1, Gear 5
:
500.0 rpm
Max tap speed for Spn 1, Gear 6
:
500.0 rpm
Max tap speed for Spn 1, Gear 7
:
500.0 rpm
Max tap speed for Spn 1, Gear 8
:
500.0 rpm
Max tap speed for Spn 2, Gear 1
:
500.0 rpm
Max tap speed for Spn 2, Gear 2
:
500.0 rpm
Max tap speed for Spn 2, Gear 3
:
500.0 rpm
Max tap speed for Spn 2, Gear 4
:
500.0 rpm
Max tap speed for Spn 2, Gear 5
:
500.0 rpm
Max tap speed for Spn 2, Gear 6
:
500.0 rpm
Max tap speed for Spn 2, Gear 7
:
500.0 rpm
Proj:
AMPTEST
Appl:
AMP
Util:
Edit
F2-Project F3-Application F4-Utility
F5-Configuration
F1-File
F2-Axis
F3-Options
F4-Quick Edit!
F5-Process
Type : Lathe
AXIS: X
- linear
P1:
File :
TEST
- Solid Tapping Parameters -
Max tap speed for Spn 2, Gear 8
:
500.0 rpm
Max tap speed for Spn 3, Gear 1
:
500.0 rpm
Max tap speed for Spn 3, Gear 2
:
500.0 rpm
Max tap speed for Spn 3, Gear 3
:
500.0 rpm
Max tap speed for Spn 3, Gear 4
:
500.0 rpm
Max tap speed for Spn 3, Gear 5
:
500.0 rpm
Max tap speed for Spn 3, Gear 6
:
500.0 rpm
Max tap speed for Spn 3, Gear 7
:
500.0 rpm
Max tap speed for Spn 3, Gear 8
:
500.0 rpm
Page 4 of 4
29.0
Chapter Overview
