Rockwell Automation 8520-ARM2 9/Series CNC AMP Reference Manual Documentation Set User Manual
Page 539

Fixed Cycles
Chapter 25
25-19
Range
0.01000 to 99999.99000 seconds
Notes
This is a global parameter; the value set here applies to all axes.
This feature is not available on the 9/230 control and Grinder
configurations.
Function
This parameter is used by mill controls when operating in 7300 mode and
calling one of these cycles:
G-code
Cycle
G84
Tapping Cycle
G86
Boring cycle (spindle stop, rapid out)
This parameter is not available for lathe or grinder controls.
Use this parameter to determine the time the drilling axis remains at the
bottom of the hole (dwells) before retracting to the R-plane. Enter a dwell
duration in seconds.
For details on the operation of a dwell in a fixed cycle, refer to the P word
discussion in your programming and operation manual. The control takes
the dwell time you assign here and uses it as the value of P in the fixed
cycle format.
Important: When performing a dwell in a fixed cycle while in 7300 mode,
only a dwell in units of seconds is available. A dwell cannot be performed
in units of spindle revolutions.
Axis
Parameter
Number
All
[75]
Range
0.01000 to 99999.99000 seconds
25.11.2
Dwell Time for G84 and G86
