2 retract amount in grooving – Rockwell Automation 8520-ARM2 9/Series CNC AMP Reference Manual Documentation Set User Manual
Page 537

Fixed Cycles
Chapter 25
25-17
Function
This parameter is used for lathe controls only.
This parameter is used for the grooving cycles called by these G-codes:
G Code System
Grooving in X
Grooving in Z
A
G75
G74
B
G75
G74
C
G76
G76
This parameter determines the retraction amount “e” for the grooving
cycles. Normally for these cycles, the control attains the programmed
depth of cut in steps. It infeeds a programmed amount and retracts an
amount “e.” This cut repeats until the control has reached the programmed
depth. Enter the distance of retraction “e” for the grooving cycles.
Axis
Parameter
Number
All
[113]
Range
0.00000 to 9999.90000 mm
or
0.00000 to 393.69685 inch
Notes
This is a global parameter; the value set here applies to all axes
and processes.
25.10.2
Retract Amount in Grooving
