Tuning a Digital or Tachless Analog System
Appendix A
A-9
Table A.D
DAC Monitor Enable Values for 4 Axis Servo Cards and 9/440 CNC
(version 12.xx and Later)
Important: These DAC monitor values only apply to 9/440s,
version 12.xx and later.
Valid Parameter Values
(for 86 and/or 87):
Output to DAC (spindle port):
0
disable DAC monitor. Run normal analog out.
1
Velocity Feedback of the 1st Servo on the servo card
2
Velocity Feedback of the 2nd Servo on the servo card
3
Velocity Feedback of the 3rd Servo on the servo card
4
Velocity Feedback of the 4th Servo on the servo card
5
Velocity Feedback of the 5th Servo on the servo card
6
Velocity Feedback of the 6th Servo on the servo card
7
Following Error of the 1st Servo on the servo card
8
Following Error of the 2nd Servo on the servo card
9
Following Error of the 3rd Servo on the servo card
10
Following Error of the 4th Servo on the servo card
11
Following Error of the 5th Servo on the servo card
12
Following Error of the 6th Servo on the servo card
13
Velocity Integrator Accum from the 1st Servo on the servo card
14
Velocity Integrator Accum from the 2nd Servo on the servo card
15
Velocity Integrator Accum, from the 3rd Servo on the servo card
16
Velocity Integrator Accum, from the 4th Servo on the servo card
17
Velocity Integrator Accum, from the 5th Servo on the servo card
18
Velocity Integrator Accum, from the 6th Servo on the servo card
19
Velocity Error from the 1st Servo on the servo card
20
Velocity Error from the 2nd Servo on the servo card
21
Velocity Error from the 3rd Servo on the servo card
22
Velocity Error from the 4th Servo on the servo card
23
Velocity Error from the 5th Servo on the servo card
24
Velocity Error from the 6th Servo on the servo card
25
Course Iteration Incremental Position Command for the 1st Servo on the
servo card
26
Course Iteration Incremental Position Command for the 2nd Servo on the
servo card
27
Course Iteration Incremental Position Command for the 3rd Servo on the
servo card
28
Course Iteration Incremental Position Command for the 4th Servo on the
servo card (typically the spindle)
29
Course Iteration Incremental Position Command for the 5th Servo on the
servo card (typically the spindle)
