2 writing amp to flash – Rockwell Automation 8520-ARM2 9/Series CNC AMP Reference Manual Documentation Set User Manual
Page 722

Patch AMP
Chapter 41
41-20
Parameter
Patch AMP Value
Default Value
Parameter Name
1800
2800
3800
Velocity Integral Gain
82
33 to 32,768
1801
2801
3801
Velocity proportional gain
17408
0 to 65,536
When you modify AMP using patch AMP you are editing a copy of AMP
that is in volatile memory (maintained by a supercap or lithium battery).
Once you have completed all of your modifications to AMP you should
write AMP to flash memory. Flash memory is a non-volatile area of
memory (maintains AMP even if supercap or lithium battery loses its
charge).
To save a copy of your AMP changes off of the control we recommend
backing up your final AMP configuration by uploading to your ODS
workstation.
END OF CHAPTER
41.2
Writing AMP to Flash
