Tuning a Digital or Tachless Analog System
Appendix A
A-7
DAC Monitor Parameters
Function
# 133
#133 enables the DAC monitor on the third servo
board of 9/260 and 9/290 systems.
# 950
Scales the DAC output for #133.
Enable the DAC monitor on your system by setting parameters 86, 87, or
133, depending on which servo card you wish to enable, as follows. These
values are different between the three axis servo cards and four axis servo
cards:
Table A.B
DAC Monitor Enable Values for 3 Axis Servo Cards and all 9/230 Systems
Important: These DAC monitor values only apply to version 11.xx and
earlier. The 3--axis servo and 9/230 systems are not supported by versions
12.xx and later.
Valid Parameter Values
(for 86, 87, and 133):
Output to DAC (spindle port):
0
disable DAC monitor. Run normal analog out.
5
Velocity Feedback of the 1st Servo on the servo card
6
Velocity Feedback of the 2nd Servo on the servo card
7
Velocity Feedback of the 3rd Servo on the servo card
8
Following Error of the 1st Servo on the servo card
9
Following Error of the 2nd Servo on the servo card
10
Following Error of the 3rd Servo on the servo card
11
Velocity Integrator Accum from the 1st Servo on the servo card
12
Velocity Integrator Accum from the 2nd Servo on the servo card
13
Velocity Integrator Accum, from the 3rd Servo on the servo card
14
Velocity Error from the 1st Servo on the servo card
15
Velocity Error from the 2nd Servo on the servo card
16
Velocity Error from the 3rd Servo on the servo card
17
Course Iteration Incremental Position Command for the 1st Servo on the
servo card
18
Course Iteration Incremental Position Command for the 2nd Servo on the
servo card
19
Course Iteration Incremental Position Command for the 3rd Servo on the
servo card
20
Course Iteration Incremental Position Command for the 4th Servo on the
servo card (typically the spindle)
21
Interpolated Final Velocity command for the 1st Servo on the servo card
22
Interpolated Final Velocity command for the 2nd Servo on the servo card
23
Interpolated Final Velocity command for the 3rd Servo on the servo card
24
Interpolated Final Velocity command for the 4th Servo on the servo card
