Using AMP Applications and ODS Utilities
Chapter 2
2-11
To select an AMP parameter group:
1.
Move the cursor to the desired group, then press
[ENTER]
.
When you have selected the Axis Parameters group, this screen is
displayed:
Proj:
AMPTEST
Appl:
AMP
Util:
Edit
F2-Project F3-Application F4-Utility
F5-Configuration
F1-File
F2-Axis
F3-Options
F4-Quick Edit!
F5-Process
Type : Lathe
AXIS: X
P1:
File :
TEST
- Axis Parameters -
Axis One’s Name
:
X
Axis Two’s Name
:
Y
Axis Three’s Name
:
Z
Axis Four’s Name
:
U
Axis Five’s Name
:
V
Axis Six’s Name
:
W
Axis Seven’s Name
:
C
Axis Eight’s Name
:
A
Axis Nine’s Name
:
B
Axis Ten’s Name
:
$X
Axis Eleven’s Name
:
$Y
Axis Twelve’s Name
:
$Z
Axis Thirteen’s Name
:
$B
Page 1 of 4
To set a parameter value:
1.
Select the parameter by cursoring to the parameter you want and
press
[Enter]
.
There are two types of parameters:
Parameters that prompt for a numeric value; these require that the
numeric value be entered within a certain range. To specify a new
value, type in the new numeric value, then press
[ENTER]
Parameters that give a choice of selections from a list of fixed
values displayed on the workstation; one of these choices must be
selected. To specify a new value, select the desired selection, then
press
[ENTER]
Important: For additional information on a parameter, press and hold the
[Alt]
key down and then press the
[H]
key to display a Help message for
each parameter.
2.
Select or enter a new value.
The workstation stores the new value and returns to the selected
parameter group menu.
3.
Press the
[ESC]
key to return to the group selection screen.
2.7
Setting Parameter Values
