1 css parameters, Use these parameters to configure the css feature, Constant surface speed chapter 11 – Rockwell Automation 8520-ARM2 9/Series CNC AMP Reference Manual Documentation Set User Manual
Page 324

Constant Surface Speed
Chapter 11
11-2
When you select the “CSS Parameters” group from the main menu, the
workstation displays this screen:
Proj:
AMPTEST
Appl:
AMP
Util:
Edit
F2-Project F3-Application F4-Utility
F5-Configuration
F1-File
F2-Axis
F3-Options
F4-Quick Edit!
Control Type:
Cylindrical
Axis :
X - linear
File :
TEST
- CSS Parameters -
Default CSS axis name
:
X
CSS axis name for P1
:
X
CSS axis name for P2
:
Y
CSS axis name for P3
:
Z
CSS axis name for P4
:
U
CSS axis name for P5
:
V
CSS axis name for P6
:
W
CSS axis name for P7
:
A
CSS axis name for P8
:
B
CSS axis name for P9
:
C
CSS Radius during G00 rapid
:
Programmed Endpoint
Per minute -or- per second
:
Per Second
Your screens may differ slightly, depending on your application type.
Use these parameters to configure the CSS feature:
Parameter:
Page:
Default CSS axis name
11-3
CSS axis name for P1 - P9
11-4
CSS radius during G00 rapid
11-5
Per minute -or- per second
11-6
Using synchronized spindles with CSS
11-6
11.1
CSS Parameters
