Rockwell Automation 8520-ARM2 9/Series CNC AMP Reference Manual Documentation Set User Manual
Page 693

Tuning AMP at the Machine
Chapter 40
40-15
When the
{SPNDL PARAM}
softkey is pressed, this screen is displayed
on the operator panel CRT:
ENTER VALUE:
SPINDLE PARAMETERS
MAX OUTPUT [VOLTS]
GEAR RANGE 1
10.000
GEAR RANGE 2
10.000
GEAR RANGE 3
10.000
GEAR RANGE 4
10.000
GEAR RANGE 5
10.000
GEAR RANGE 6
10.000
GEAR RANGE 7
10.000
GEAR RANGE 8
10.000
REPLCE
VALUE
ADD TO
VALUE
UPDATE
& EXIT
QUIT
NEXT
SPINDL
When the control displays this screen, the cursor will be shown on
the value GEAR RANGE 1 in the MAX OUTPUT column.
3.
Use the up or down cursor keys to highlight the spindle parameter
value that is to be changed.
To replace the current spindle parameter value:
press the
{REPLCE VALUE}
softkey
cursor to the position you want
key-in the new value
press
[TRANSMIT]
To add to the current spindle parameter value:
press the
{ADD TO VALUE}
softkey
cursor to the position you want
key-in the new value
press
[TRANSMIT]
