Chapter
16
16-1
Axis Program Format Parameters
This chapter covers the Axis Program Format parameters. These
parameters specify the word formats that must be used when specifying
axis position and/or distance in part programs. The specified format limits
the number of digits that may be entered to the left and to the right of the
decimal point when entering an axis word. There are additional
parameters in this group that can be set to determine zero suppression and
error checking if a letter or number is missing.
The workstation displays this screen after you select the “Axis Program
Format” group:
Proj:
AMPTEST
Appl:
AMP
Util:
Edit
F2-Project F3-Application F4-Utility
F5-Configuration
F1-File
F2-Axis
F3-Options
F4-Quick Edit!
F5-Process
Type:
Lathe
AXIS: X
P1:
File :
TEST
- Axis Program Format -
Axis 1 Word Format
:
3.4 inch and 4.3 metric
Axis 2 Word Format
:
3.4 inch and 4.3 metric
Axis 3 Word Format
:
3.4 inch and 4.3 metric
Axis 4 Word Format
:
3.4 inch and 4.3 metric
Axis 5 Word Format
:
3.4 inch and 4.3 metric
Axis 6 Word Format
:
3.4 inch and 4.3 metric
Axis 7 Word Format
:
3.4 inch and 4.3 metric
Axis 8 Word Format
:
3.4 inch and 4.3 metric
Axis 9 Word Format
:
3.4 inch and 4.3 metric
Axis 10 Word Format
:
3.4 inch and 4.3 metric
Axis 11 Word Format
:
3.4 inch and 4.3 metric
Axis 12 Word Format
:
3.4 inch and 4.3 metric
Leading zero suppression mode
:
Disabled
The parameter values shown above are the default values of these
parameters. These values specify that:
When the control
is in:
No. of digits that may be entered to
the left of the decimal point:
No. of digits that may be entered to
the right of the decimal point:
Inch Mode
3
4
Metric Mode
4
3
16.0
Chapter Overview
