Plane Select Parameters
Chapter 18
18-10
A value for this parameter may be chosen from these allowable axis
names: A, B, C, U, V, W, X, Y, Z, $B, $C, $X, $Y, or $Z. A value of
“None” may also be selected indicating that there are not two axes parallel
to that primary axis in the plane selected with that G-code.
Important: Do not use this parameter if a value has not been set for the
parameter that assigns the 1st axis parallel to a primary axis.
Parameter
Parameter Number
Single
Mill
Dual Mill
Process 1
Dual Mill
Process 2
Single
Lathe
Dual Lathe
Process 1
Dual Lathe
Process 2
G17 2nd axis parallel to 2
[546]
[20546]
[21575]
[575]
[20575]
[21575]
G18 2nd axis parallel to 2
[552]
[20552]
[21552]
[552]
[20552]
[21552]
G19 2nd axis parallel to 2
[558]
[20558]
[21581]
[581]
[20581]
[21581]
Range
Selection
Results
Selection
Results
(a)
A
(i)
Z
(b)
B
(j)
$B
(c)
C
(k)
$C
(d)
U
(l)
$X
(e)
V
(m)
$Y
(f)
W
(n)
$Z
(g)
X
(o)
none
(h)
Y
Notes
This is a global parameter; the value set here applies to all axes.
For Dual Processing controls, this is a per process parameter. The value set
in the parameters applies to all of the axes assigned to that process.
Important: If you are performing planar functions on parallel axes, both
the parallel axis and the primary axis must be defined to use the same
integrand word.
END OF CHAPTER
