AlliedView™-EMS 4.0.3 Device Management Guide

Page 440 of 468

LED

State

Description

DUP

Green

Orange

The port is operating in full-duplex mode.

The port is operating in half-duplex mode.

LT

Green

Link Test is enabled

OAMB

Green

OAM Bypass is enabled

OAMV

Green

OAM Visible is enabled

LCDS

Green

Line Card Dip Switch is enabled

Note

- The current firmware version will not allow remote port connection on the RJ-45

port if the SFP port is set to disabled.

Note

- The Module Name parameter always displays 'yyyyyyyy' as its default value when

not yet configured.

Note

- AT-CV5M01: The current firmware version does not allow the Port Mode

parameter of FX type of ports to be configured. Attempting to configure this parameter

other than its current Port Mode value will result in the error message: "noSuchName."


Remote Line Card Info

Note

- Even if the current firmware version allows the Remote Port Mode

parameter to be configured to certain values, this parameter should not be

configured for the 100Base-FX port.

Port Info

Note

- The value of the Port Speed and Port Duplex parameters of a port with an

established link automatically changes to '10Mbps' and 'half duplex' when the value

of its Port Mode parameter is changed from 'auto' to 'manual'.

Note

- The current firmware version does not allow Device Manager to configure

or display information on the T1/E1 port of the AT-CM70S.

Note

- The value of the Port Speed and Port Duplex parameters of a port with an

established link automatically changes to '10Mbps' and 'half duplex' when the value

of its Port Mode parameter is changed from 'auto' to 'manual'.

Note

- The current firmware version does not allow the Port Ingress Rate Limit and

Port Egress Rate Limit parameters to be configured.

Context Menu

Note

- Selecting the Telnet option in the RS-232 Terminal Port Context Menu of the

AT-CM70S will establish a Telnet session to the AT-CV5M01 management module.
