Device Manager LEDs for the AT-x900-12X Series

FAN Green

Gray

The Fan Module is installed and functioning in the PSU bay.

The Fan Module is either not installed or not functioning in the

PSU bay.

DUPLEX Green

Orange

The port is operating at full duplex.

The port is operating at half duplex.

STACK ID Green

Gray

Orange

The stacked unit is either the Stacking Master or the Backup

Master.

The switch is set to standalone mode.

The stacked unit is a slave switch.

Note

- Please refer to Uplink Modules for the operations and behavior of the Expansion

Modules installed on these devices.

Note

- The current firmware version does not allow Device Manager to support the PWR

and FAN LEDs.

Note

- Status information for combo ports will always be reflected on both the RJ-45 port

images and the SFP port images regardless of whether it is the RJ-45 or the SFP ports that

are actually in operation.

Note

- The current firmware version does not allow the Device Manager to re-establish

connection after removing the stack member and the stacking module of the device.

To prevent this, the stacking module may need to be re-installed or the provisioning

configuration may need to be removed followed by a device reboot.

Agent Menu

From the Agent menu, you can view and edit the system information for the switch, or log

into the CLI using Telnet.

System Info

Standard

Displays basic system information, including system name, location, contact

and description.

Note

- Valid MIB Set values for the System Contact and System Location

parameters are up to 255 characters. Attempting to enter values greater

than the valid range will be accepted but values exceeding 255 characters will

be truncated.
