AlliedView™-EMS 4.0.3 Device Management Guide

Page 405 of 468

Device Manager LEDs for the SwitchBlade x908

LED

State

Description

PWR 1

Green

Gray

The Power Supply Unit (PSU) is installed and functioning in the

PSU bay 1.

The Power Supply Unit (PSU) is either not installed or not

functioning in the PSU bay 1.

PWR 2

Green

Gray

The Power Supply Unit (PSU) is installed and functioning in the

PSU bay 2.

The Power Supply Unit (PSU) is either not installed or not

functioning in the PSU bay 2.

FAN 1

Green

Gray

The fan module is installed and functioning in the Fan bay 1.

The fan module is either not installed or not functioning in the
Fan bay 1.

FAN 2

Green

Gray

The fan module is installed and functioning in the Fan bay 2.

The fan module is either not installed or not functioning in the

Fan bay 2.

STACK ID Green

Gray

Orange

The stacked unit is either the Stacking Master or the Backup

Master.

The switch is set to standalone mode.

The stacked unit is a slave switch.

Note

- Please refer to Uplink Modules for the operations and behavior of the Expansion

Modules installed on the chassis.

Note

- The current firmware version does not allow Device Manager to support the FAN

LEDs.

Agent Menu

From the Agent menu, you can view and edit the system information for the switch, or log

into the CLI using Telnet.

System Info

Standard

Displays basic system information, including system name, location, contact

and description.

Note

- Valid MIB Set values for the System Contact and System Location

parameters are up to 255 characters. Attempting to enter values greater
