AlliedView™-EMS 4.0.3 Device Management Guide

Page 275 of 468

AT-9748TS/XP

(With 10G Uplink)

AT-9748TS/XP

(No Uplink)

AT-9724TS

0

1

<=11

Device Manager LEDs for AT-9700 Series

LED

State

Description

PWR

Green

The switch is receiving power from the main power supply.

RPS Green

Gray

The switch is receiving power from the redundant power supply.

RPS is not installed or not functioning.

STACK ID Green

Orange

The stacked unit is either a slave switch or the switch is not in a

stacked mode.

The stacked unit is the master switch.

DUPLEX Green

Orange

The port is operating in full-duplex mode.

The port is operating in half-duplex mode.

Note

- The Stack ID LED indicates the Box ID of the stacked switch or standalone switch.

Note

- When multiple units of the AT-9700 series are stacked together, port numbering

is continuous based on the Box ID.

Box ID 1 - 1 to 64

Box ID 2 - 65 to 128

Box ID 3 - 129 to 192

Box ID 4 - 193 to 256

Box ID 5 - 257 to 320

Box ID 6 - 321 to 384

Box ID 7 - 385 to 448

Box ID 8 - 449 to 512

Box ID 9 - 513 to 576

Box ID 10 - 577 to 640

Box ID 11 - 641 to 704

Box ID 12 - 705 to 768

This numbering scheme assumes that a unit can have a maximum of 64 ports.

Note

- The current firmware version does not allow Device Manager to detect the presence

or absence of an SFP module in any of the SFP slots. As a result, the SFP slots on the device

image will always show SFP images regardless of whether or not SFP modules are physically

present in the slots.
