AlliedView™-EMS 4.0.3 Device Management Guide

Page 316 of 468

Device Manager LEDs for the AT-x600 Series

Orange

The switch is set to standalone mode.

The stacked unit is a slave switch.

Note

- Please refer to Uplink Modules for the operations and behavior of the Expansion

Modules installed on these devices.

Note

- The current firmware version does not allow Device Manager to support the PWR

and RPS LEDs.

Note

- Status information for combo ports will always be reflected on both the RJ-45 port

images and the SFP port images regardless of whether it is the RJ-45 or the SFP ports that

are actually in operation.

Note

- The current firmware version does not allow the Device Manager to re-establish

connection after removing the stack member and the stacking module of the device. To

prevent this, the stacking module may need to be re-installed or the provisioning

configuration may need to be removed followed by a device reboot.

Agent Menu

From the Agent menu, you can view and edit the system information for the switch, or log

into the CLI using Telnet.

System Info

Standard

Displays basic system information, including system name, location, contact

and description.

Note

- Valid MIB Set values for the System Contact and System Location

parameters are up to 255 characters. Attempting to enter values greater
than the valid range will be accepted but values exceeding 255 characters will

be truncated.

Note

- Valid MIB Set values for the System Name parameter is up to 255

characters. However, values exceeding 64 characters will be truncated.

Note

- The current firmware version allows the System Name parameter to

be set to 'NULL'. However, attempting to set this parameter to value 'NULL'

will set it to its default value 'awplus'.

Enterprise

CPU Utilization

Displays information about the CPU utilization over different periods

of time.
