AlliedView™-EMS 4.0.3 Device Management Guide

Page 184 of 468

Device Manager LEDs for AT-8600 Series

Gray

RPS is not installed or RPS monitoring is disabled.

DUPLEX Green

Orange

The port is operating at full duplex.

The port is operating at half duplex.

Note

- At device start-up, the current firmware version returns 'operational' status for all

ports. As a result, RJ-45 SFP port image will appear on ports 49-50 even if there is no SFP

module inserted.

Note

- The current firmware version does not allow Device Manager to support the Reset

button.

Agent Menu

From the Agent menu, you can view and edit the system information for the switch, or log

into the CLI using Telnet.

System Info

Displays basic system information, including system name, location, contact and

description.


Power Supply Info

Displays information about the power supply, redundant power supply and power

supply monitoring.


File List

Displays a list of the files in the switch's file system.


Config File Name

Displays the file name of the start-up configuration file.


Telnet

Starts a Telnet connection to the switch.


WEB Browser

Opens your web browser and connects to the switch's HTTP server.

Note

- The web browser can only contact the device if the device has a valid

resource file loaded and set, and the HTTP server and GUI on the device are

enabled.
