56 MAESTRO Installation and Service Manual
Section 2 — Installation Planning
Figure 16. Sonata-to-Maestro Application with Fully-expanded Audio Inputs
Note A maximum of two direct Audio Mixer sources are supported in Maestro
whether or not the Audio Mixer MADI expansion is enabled.
8609_00
Video reference
AES Reference
A, B, C, & D
background
audio sources
(1-16 channels each,
arranged as 8 AES pairs)
A, B, C, & D
Audio Mixer MADI
expansion
3/4
7/8
5/6
7/8
5/6
3/4
1/2
7/8
5/6
3/4
1/2
7/8
5/6
3/4
1/2
7/8
5/6
3/4
1/2
3/4
7/8
5/6
1/2
7/8
5/6
3/4
1/2
7/8
5/6
3/4
1/2
7/8
5/6
3/4
1/2 1/2
BG A IN MON OUTS MTR OUTS ALARM PGM OUTS CF1 OUTS BG B IN MON IN OVER B IN OVER A IN
Pgm & CF1 audio
outputs (1-8
channels each)
Audio outputs to other equipment Audio inputs from other equipment
INPUTS OUTPUTS
Audio router
When not in use, AES REF
connectors must be terminated
AES reference can be used
as an alternate reference
