MAESTRO Installation and Service Manual 415
Appendix
A
Specifications
Mechanical
Table 15. Maestro Mechanical Specifications
Depth
a
a Allow a minimum of four inches behind the frames for cabling
Width Height Weight
b
b All weights approximate.
Rack Units
Main frames
4 RU Maestro/Concerto Frame 19 in. / 483 mm 19 in. / 483 mm 7 in. / 178 mm 35 lb. / 16 kg 4
8 RU Maestro/Concerto+ Frame 20.5 in. / 521 mm 19 in. / 483 mm 14 in. / 356 mm 70 lb. / 32 kg 8
MADI conversion frames
AES In / MADI Out TBD 19 in. / 483 mm 1.75 in. / 45mm TBD 1
MADI In / AES Out TBD 19 in. / 483 mm 1.75 in. / 45mm TBD 1
Analog audio In / MADI Out TBD 19 in. / 483 mm 1.75 in. / 45mm TBD 1
MADI In / Analog Audio Out TBD 19 in. / 483 mm 1.75 in. / 45mm TBD 1
Hardware control panels
MAE-4X2STD-CP approx. 5.3 in. / 133 mm approx. 25.7 in. / 653
mm
c
c Indicated measurement is for top surface of panel. For cabinet cutout dimensions, see Figure 20 on page 65 .
approx. 18.3 in. /
464 mm
c
25 lb. / 12 kg
N/A
MAE-5X2STD-CP approx. 5.3 in. / 133 mm approx. 31.5 in. / 800
mm
d
d Indicated measurement is for top surface of panel. For cabinet cutout dimensions, see Figure 21 on page 66 .
approx. 18.3 in. /
464 mm
d
33 lb. / 15 kg
N/A
GUI Control Panel
Touch screen LCD display (when
desk mounted) 8 in. / 203 mm 17.5 in. / 445 mm Minimum: 14.5 in. /
368 mm
Extended: 19.75 in. /
502 mm TBD
N/A
Touch screen LCD display (when
rack mounted) 3.75 in. / 95 mm 19 in. / 483 mm 14 in. / 356 mm TBD
8
CPU 24 in. / 610 mm 19 in. / 483 mm 7 in. / 178 mm TBD 4
Keyboard with built-in touchpad
(when desk mounted) 9.5 in. / 241 mm 15.75 in. / 400 mm 1.75 in. / 45 mm TBD
N/A
Keyboard with built-in touchpad
(when rack mounted) 13.5 in. / 343 mm 19 in. / 483 mm 1.75 in. / 45 mm TBD
1
